Home / Musicians / PA / Loudspeakers / Passive Loudspeakers / RCF Passive Loudspeaker

RCF Passive Loudspeaker

Code: PR-100215 PR-100214 PR-100218 PR-100217 PR-100216 PR-100219 Choose variant
Not rated
RCF Passive Loudspeaker
€769 €539 €1 299 €1 119 €829 €1 439 from €539
Out of Stock Out of Stock Out of Stock Out of Stock Out of Stock Out of Stock Choose variant
Power
Speakers
Sound Pressure Level (SPL)
Chosen variant is not available. Reset selected parameters.
The P1108-T is a weatherproof full range, wide-dispersion, two way loudspeaker system suitable for several indoor or outdoor applications where good speech intelligibility and music reproduction are required. In a single-piece rotational moulded UV protected polyethylene cabinet the P1108-T combines a 1,5” diaphragm assembly compression driver loaded on a 1” rotatable constant directivity 90°x60°CD horn with a 8” high efficiency low-frequency transducer with a 1.5” voice coil. The cabinet is equipped with 4 x M 8 brass inserts and a steel U-Bracket. The front logo is in aluminium and rotatable. The grille is in custom perforated aluminium with open-cell fibres and water repellent woven fabric backing. P1108-T is suitable for indoor and outdoor installations, it meets the requirements of IP 55 code (International Protection Rating).Features100 W RMSWeatherproof cabinet IP 55Aluminium grill and stainless steel bracketOne 8" high-output LF transducer with 1.5" voice coilOne RCF Precision 1" Compression Driver with 1.5" voice coil90° x 60° constant directivity horn2° x 15° enclosure sides for cluster configurationsPTC Driver ProtectionLICC (Low Impedance Compensated Crossover) network2 metres 4 x 1.5 Input cableAcoustical SpecificationsFrequency Response -10 dB: 80 Hz ÷ 20000 HzMax SPL @ 1m: 121 dBHorizontal coverage angle: 90°Vertical coverage angle: 60°Directivity index; Q: 11System Sensitivity: 95 dBNominal Impedance: 16 Power Handling: 100 WPeak Power Handling: 400 WRecommended Amplifier: 200 WProtections: Dynamic protection on Compression DriverCrossover frequencies: 2200 Hz TransducersCompression Driver: 1" throat, 1.5" coil diaphragm assemblyNominal Impedance: 8 Input Power Rating: 20 W AESSensitivity: 107 dBWoofer: 8" woofer, 1.5" voice coilNominal Impedance: 16 Input Power Rating: 100 W AESSensitivity: 94 dB Input SectionInput connector: 4 x 1.5 mm square 2 m Neoprene cableConstant voltage transformer: 70/100Power Selection: 70V/30W, 15W - 100V/60W, 30W CabinetCabinet Material: 8 mm Polyethylene rotomouldedHardware: 4 x M8 + U-Bracket and Pair of spacersGrille: Custm perforated aluminium grille with open-cell fiber and water repellent woven fabric backingColour: Grey Physical SpecificationsHeight: 266/10.47 mm/inchWidth: 493/19.40 mm/inchDepth: 250/9.84 mm/inchNet Weight: 12,5/27.55 kg/lbs.

Detailed information

Product detailed description

The P1108-T is a weatherproof full range, wide-dispersion, two way loudspeaker system suitable for several indoor or outdoor applications where good speech intelligibility and music reproduction are required. In a single-piece rotational moulded UV protected polyethylene cabinet the P1108-T combines a 1,5” diaphragm assembly compression driver loaded on a 1” rotatable constant directivity 90°x60°CD horn with a 8” high efficiency low-frequency transducer with a 1.5” voice coil. The cabinet is equipped with 4 x M 8 brass inserts and a steel U-Bracket. The front logo is in aluminium and rotatable. The grille is in custom perforated aluminium with open-cell fibres and water repellent woven fabric backing. P1108-T is suitable for indoor and outdoor installations, it meets the requirements of IP 55 code (International Protection Rating).Features100 W RMSWeatherproof cabinet IP 55Aluminium grill and stainless steel bracketOne 8" high-output LF transducer with 1.5" voice coilOne RCF Precision 1" Compression Driver with 1.5" voice coil90° x 60° constant directivity horn2° x 15° enclosure sides for cluster configurationsPTC Driver ProtectionLICC (Low Impedance Compensated Crossover) network2 metres 4 x 1.5 Input cableAcoustical SpecificationsFrequency Response -10 dB: 80 Hz ÷ 20000 HzMax SPL @ 1m: 121 dBHorizontal coverage angle: 90°Vertical coverage angle: 60°Directivity index; Q: 11System Sensitivity: 95 dBNominal Impedance: 16 Power Handling: 100 WPeak Power Handling: 400 WRecommended Amplifier: 200 WProtections: Dynamic protection on Compression DriverCrossover frequencies: 2200 Hz TransducersCompression Driver: 1" throat, 1.5" coil diaphragm assemblyNominal Impedance: 8 Input Power Rating: 20 W AESSensitivity: 107 dBWoofer: 8" woofer, 1.5" voice coilNominal Impedance: 16 Input Power Rating: 100 W AESSensitivity: 94 dB Input SectionInput connector: 4 x 1.5 mm square 2 m Neoprene cableConstant voltage transformer: 70/100Power Selection: 70V/30W, 15W - 100V/60W, 30W CabinetCabinet Material: 8 mm Polyethylene rotomouldedHardware: 4 x M8 + U-Bracket and Pair of spacersGrille: Custm perforated aluminium grille with open-cell fiber and water repellent woven fabric backingColour: Grey Physical SpecificationsHeight: 266/10.47 mm/inchWidth: 493/19.40 mm/inchDepth: 250/9.84 mm/inchNet Weight: 12,5/27.55 kg/lbs.
